E23534362
Turbocharger for Series 60, EPA04, 12L, VNT, GT4502V, High Mount
Detroit Diesel
BACK ORDERED
Please contact us for information on lead time
This truck part is made by Detroit Diesel. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
This high-mount VNT turbocharger for the Series 60 EPA04 12L engine offers advanced exhaust and intake management. With a turbine exducer diameter of approximately 122.70 mm and an inducer of 78.68 mm, it efficiently converts exhaust gases into rotational energy. The variable nozzle technology enhances boost control, resulting in improved throttle response and fuel economy across various engine loads. Its compressor side features a diameter of about 107 mm, with an inducer of 70.91 mm, designed to supply high airflow volumes required in heavy-duty applications. The turbo’s overall dimensions allow for installation in high-mount configurations, optimizing space and performance. Built to withstand rigorous operating conditions, this turbocharger promotes engine reliability and efficiency. Source One Parts Center offers this high-quality turbo, ensuring it meets the demanding standards of modern diesel engines.
SPECIFICATIONS
VMRS
043-004-001
Compressor Outlet Outer Diameter
107 mm
Mounting Hole Diameter
11 mm
Turbine Outlet Outer Diameter
122.70 mm
Compressor Inlet Outer Diameter
129.03 mm
Micron Rating
20 microns
Maximum Rated Revolutions Per Minute
2100 RPM
Inlet Oil Pressure
30 psi
Overall Length
301.19 mm
Compressor Outlet Inner Diameter
82.35 mm
Oil Inlet Inner Diameter
9.53 mm
OEM Part Number
DDE E23534362
Fuel Type
Diesel
OEM Description
TURBOCHARGER - SERIES 60, EPA04, 12L, VNT, GT4502V, HIGH MOUNT
CROSS REFERENCES
- DDE R23534362, R23534362, DDE-R23534362, DDER23534362
