R23518610
Remanufactured Fuel Pump Assembly for Series 50 RH 12L DDEC IV
Detroit Diesel
AVAILABLE
5 are currently available
Ships within 6-8 business days
This truck part is made by Detroit Diesel. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
This remanufactured fuel pump assembly is designed for Series 50 engines equipped with DDEC IV, ensuring consistent fuel delivery and optimal engine operation. Its compact dimensions include a height of 3.92 inches and a length of 4.5 inches, with inlet and outlet ports threaded for 3/8-18 NPT fittings. Capable of reaching speeds up to 2750 RPM and delivering a continuous pressure of 3000 psi, it supports high-demand applications with reliable fuel regulation. The assembly features a spool-type shaft and a built-in bypass relief valve set at 90 psi to prevent over-pressurization. Manufactured with precision components, it guarantees durability and long service life. This pump is essential for maintaining proper fuel flow, engine efficiency, and emissions compliance in heavy-duty truck engines. Source One Parts Center offers this remanufactured unit, ensuring quality and performance.
SPECIFICATIONS
Mounting Hole Diameter
0.35 in
VMRS
044-003-027
Drain Thread Size
1/8-27 NPTF in
Capacity
12 L
Flow Capacity
2.20 gpm
Bolt Circle Diameter
2.88 in
Maximum Speed
2750 RPM
Mounting Hole Quantity
3
Displacement
3.18 cc/rev
Height
3.92 in
Inlet Port Thread Size
3/8-18 NPT in
Outlet Port Thread Size
3/8-18 NPT in
Continuous Pressure Rating
3000 psi
Length
4.50 in
Intermittent Pressure Rating
4000 psi
Bypass Relief Valve Setting
90 psi
Rotation Direction
Clockwise
OEM Part Number
DDE R23518610
OEM Description
FUEL PUMP ASSEMBLY, REMAN,SERIES 50 RH 12L DDEC IV
Inlet Fitting Type
Female Thread
Manufacturing Type
Remanufactured
Shaft Type
Spider Coupling
CROSS REFERENCES
- DDE 23518610, 23518610, DDE-23518610, DDE23518610
