4009242
Lubricating Oil Filter Head
Cummins®

Introduction

The Lubricating Oil Filter Head is a critical component in the engine system, essential for maintaining engine performance and longevity. It facilitates the filtration of lubricating oil, ensuring contaminants are removed before the oil circulates through the engine. This process is vital for preserving the integrity of engine components and enhancing overall engine efficiency ¹.

Function and Operation

The Lubricating Oil Filter Head directs the flow of oil from the engine to the oil filter. As oil passes through the filter, impurities and debris are trapped, allowing only clean oil to return to the engine. This filtration process is essential for maintaining the lubrication of moving parts, reducing wear, and preventing the buildup of harmful deposits within the engine system ².

Purpose of the 4009242 Lubricating Oil Filter Head

The 4009242 Lubricating Oil Filter Head is designed to enhance the operation of trucks by ensuring efficient and reliable oil filtration. By providing clean oil to the engine, it contributes to improved engine efficiency and reliability, helping to maintain optimal performance under various driving conditions ³.

Key Features

The 4009242 Lubricating Oil Filter Head features a robust design that ensures durability under high-pressure conditions, the use of high-quality materials to resist corrosion and wear, and precise engineering to ensure a secure fit and efficient oil flow.

Benefits

Utilizing the 4009242 Lubricating Oil Filter Head offers several benefits. It provides improved engine protection by ensuring that only clean oil circulates through the engine, enhances oil filtration efficiency, and contributes to increased engine lifespan by reducing wear on critical components ⁴.

Installation Process

Proper installation of the 4009242 Lubricating Oil Filter Head involves several steps. Begin by ensuring the engine is cool and the oil has been drained. Remove the old filter head, clean the mounting surface, and apply a light coat of oil to the gasket of the new filter head. Carefully install the new head, ensuring it is securely fastened. Finally, refill the engine with the appropriate type and amount of oil.

Maintenance Tips

To ensure the Lubricating Oil Filter Head remains in optimal condition, regular maintenance is recommended. This includes inspecting the head for signs of wear or damage at regular intervals, cleaning the mounting surface before installation, and following manufacturer guidelines for replacement to ensure continued efficient operation.

Troubleshooting Common Issues

Common issues associated with the Lubricating Oil Filter Head may include leaks or performance issues. To address these, first, ensure the head is correctly installed and securely fastened. If leaks persist, inspect the gasket for damage and replace if necessary. Performance issues may indicate a need for replacement or further inspection of the oil filtration system.

Manufacturer - Cummins

Cummins is a renowned name in the automotive industry, known for its commitment to producing high-quality engine components. With a rich history of innovation and excellence, Cummins has established a reputation for reliability and performance in the production of engine parts, including the 4009242 Lubricating Oil Filter Head.

Cummins Engine Compatibility with Lubricating Oil Filter Head Part 4009242

The Cummins lubricating oil filter head part 4009242 is designed to fit seamlessly with several engine models, ensuring optimal performance and reliability. This part is integral to the engine’s oil filtration system, which is crucial for maintaining engine health.

KTA19GC and KTA19GC CM558

The KTA19GC and KTA19GC CM558 engines are part of Cummins’ industrial and marine engine series. The 4009242 oil filter head is specifically engineered to fit these models, providing a secure and efficient connection to the engine’s oil system. This ensures that the oil is properly filtered, removing contaminants that could otherwise cause wear and damage.

QSK19 CM500 and QSK19 CM850 MCRS

The QSK19 CM500 and QSK19 CM850 MCRS engines are high-performance models within Cummins’ QSK series. These engines are used in a variety of applications, from marine to power generation. The 4009242 oil filter head is compatible with both models, ensuring that the oil filtration system operates smoothly and effectively. This compatibility is crucial for maintaining the high standards of performance and reliability expected from these engines.

QSK19G

The QSK19G engine is another model within Cummins’ QSK series, known for its robust performance and efficiency. The 4009242 oil filter head is designed to fit this engine, providing a critical component of the oil filtration system. This ensures that the engine operates at peak efficiency, with contaminants effectively removed from the oil.

Role of Part 4009242 Lubricating Oil Filter Head in Engine Systems

The 4009242 Lubricating Oil Filter Head is an integral component in the efficient operation of engine systems, particularly in the management and maintenance of lubricating oil. This part is designed to interface with the full-flow oil filter system, ensuring that the oil circulating through the engine is adequately filtered before it reaches critical engine components.

In the context of engine lubrication, the oil filter head serves as a junction point. It connects the full-flow oil filter to the engine’s lubrication system. As oil is pumped from the oil pan by the oil pump, it passes through the filter head into the full-flow oil filter. The filter media within the full-flow oil filter traps contaminants and particles, ensuring that only clean oil circulates through the engine.

The lubricating oil, after being filtered, flows from the filter head to various engine components such as the crankshaft, camshaft, pistons, and bearings. This clean oil is essential for reducing friction, dissipating heat, and preventing wear on these moving parts. The efficiency of the 4009242 Lubricating Oil Filter Head in this process directly impacts the longevity and performance of the engine.

Additionally, the filter head often incorporates a bypass valve. This valve is designed to allow oil to bypass the filter if the filter becomes clogged, ensuring that the engine continues to receive lubrication even in compromised conditions. This feature is vital for maintaining engine operation and preventing damage due to lack of lubrication.

Conclusion

The 4009242 Lubricating Oil Filter Head by Cummins plays a significant role in the lubrication system by facilitating the filtration of oil before it is distributed to engine components, thereby ensuring optimal engine performance and longevity. Its robust design, compatibility with various Cummins engine models, and the incorporation of a bypass valve make it a critical component for maintaining engine health and efficiency.
