K121565N
Bracket Assembly
Bendix

A large‑format mounting frame sharing the same exterior footprint as other members in this bracket family, designed to support a broader class of axle brake systems while preserving the intended geometry for the cam/lever cluster. The 365 mm width, 292 mm height, and 269 mm length with an overall 10.56 inch length fit a wide range of drum housings and facilitate retrofit and standardization across fleets. The design prioritizes stiffness and corrosion resistance to maintain alignment under repeated braking cycles and heat. VMRS 013-010-272 provides consistent classification for planning and stocking in the Bendix catalog. Technicians should verify mounting hole alignment, edge clearances, and surface finish during replacement to minimize wear on the shoes and maintain uniform drum wear patterns for reliable performance in highway, municipal, and off‑road service.
