DESCRIPTION
Bendix's Bracket Assembly is a pivotal component designed to enhance the effectiveness of your commercial vehicle's braking system. This assembly ensures proper support for air chambers and camshafts, contributing to overall braking performance and safety. Crafted from high-quality materials, it is engineered for durability and longevity, making it suitable for the demands of heavy-duty applications. The nylon bushings provide additional resilience, while the straightforward installation process minimizes downtime, allowing your fleet to remain operational. Investing in this bracket assembly means prioritizing both safety and performance for your vehicle. For genuine Bendix OEM parts, Source One Parts Center is your best source, offering exceptional quality and service tailored for commercial vehicles.
SPECIFICATIONS
VMRS
013-017-009: Bracket - Chamber, Position Not Specified
Length (Centerline to Centerline) [IN]
16.31
Length (Basic Weld Set)
2.563 IN
Gusset Angle
40°
Length (Slack Length)
5.50 IN - 6.00 IN
Camshaft Bracket Angle
70° CW
Harmonized System (HS) Code
870830
Inboard Bushing
Nylon
Outboard Bushing
Nylon
Arm Style
Scalloped
Gusset
Single
Country of Origin
United States
Weight
16.14 lb
