K077714
Bracket Assembly
Bendix
UNAVAILABLE
FINAL SALE. No returns or exchanges.
This truck part is made by Bendix. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
The Bracket Assembly is a key element in your vehicle's braking system, offering essential support and alignment for optimal brake performance. Designed with a full arm style and featuring robust nylon bushings, this assembly is engineered to endure the demands of heavy-duty applications. Its camshaft bracket angle of 40° CCW ensures effective brake operation, contributing to the safety and responsiveness of your vehicle. This versatile part is suitable for a variety of setups, making it an ideal choice for maintenance and upgrades. Source One Parts Center is your trusted source for authentic Bendix OEM parts, providing quality components that enhance the reliability of your commercial vehicles.
SPECIFICATIONS
VMRS
013-017-009: Bracket - Chamber, Position Not Specified
Length (Basic Weld Set)
1.063 IN
Length (Centerline to Centerline) [IN]
11.56
Gusset Angle
40°
Length (Slack Length)
5.50 IN - 6.00 IN
Camshaft Bracket Angle
75° CCW
Harmonized System (HS) Code
870830
Outboard Bushing
Bronze
Arm Style
Full
Inboard Bushing
Nylon
Gusset
Single
Country of Origin
United States
Weight
12.49 lb
