K070228
Bracket Assembly
Bendix
UNAVAILABLE
FINAL SALE. No returns or exchanges.
This truck part is made by Bendix. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
The Bracket Assembly from Bendix is engineered to provide robust support for foundation drum brakes, ensuring reliability and performance in commercial vehicles. Featuring a single gusset design and a full arm style, this bracket is built to withstand the demands of heavy-duty applications. Made with durable nylon bushings, it reduces friction and enhances operational efficiency, making it a preferred choice for fleet maintenance. This assembly is designed for easy installation, allowing for quick and efficient replacement of worn or damaged brackets. With precise dimensions tailored for compatibility, you can trust in Bendix's quality. For top-quality Bendix OEM parts, Source One Parts Center is your best resource, ensuring you receive authentic components for your fleet.
SPECIFICATIONS
VMRS
013-017-009: Bracket - Chamber, Position Not Specified
Length (Basic Weld Set)
1.063 IN
Length (Centerline to Centerline) [IN]
15.06
Gusset Angle
40°
Length (Slack Length)
5.50 IN - 6.00 IN
Camshaft Bracket Angle
55° CW
Harmonized System (HS) Code
870830
Arm Style
Full
Inboard Bushing
Nylon
Outboard Bushing
Nylon
Gusset
Single
Country of Origin
United States
Weight
14.31 lb
