2598108C91
DIFFERENTIAL ASSEMBLY FRONT /REAR
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$6,499.95
$7,799.94
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
DIFFERENTIAL ASSEMBLY FRONT /REAR
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| NUT, HEXAGON LOCK PINION | 1 | 1685173C1 |
| CUP, BEARING | 1 | FPHM813810 |
| ADAPTER LUBE FILTER | 1 | 1670526C1 |
| SCREEN, OIL FILTER | 1 | 1670482C1 |
| SEAL, SHIFT MOTOR TO CARRIER | 1 | 1696235C1 |
| CLIP, DCDL SENSOR SWITCH | 1 | 2501792C1 |
| WASHER, FLAT PINION SHAFT WITH NUT 3" O.D. X 1.78" I.D. X .19" THICK | 1 | 264663C1 |
| BEARING, CONE PINION | 1 | FPHM813843 |
| SHAFT, INPUT POWER DIVIDER LOCK | 1 | 1691801C91 |
| WASHER HELICAL GEAR TO PIN GEA | 1 | 2594597C1 |
| WASHER HELICAL GEAR TO PIN GEA | 1 | 1670272C1 |
| GEAR, HELICAL DRIVE DIFFERENTIAL | 1 | 1694576C1 |
| BOLT, INTERAXLE DIFFERENTIAL M10 X 45 MM | 8 | 1696237C1 |
| WASHER, FLAT M10 | 8 | 1658423C1 |
| SPIDER, DIFFERENTIAL | 1 | 1694573C1 |
| GEAR, SPIDER DIFFERENTIAL | 4 | 1694555C1 |
| WASHER, THRUST | 4 | 588968C1 |
| RING, SNAP | 1 | 1670296C1 |
| COLLAR, SHIFT CLUTCH I.A.D. | 1 | 2500880C1 |
| COLLAR, SHIFT CLUTCH | 1 | 2506149C1 |
| GEAR, SIDE DIFFERENTIAL | 1 | 1694570C1 |
| YOKE, SHIFT AXLE | 1 | 1670264C91 |
| BEARING, CONE REAR /REAR | 1 | FPJLM714149 |
| CUP, BEARING FRONT AND REAR | 1 | FPJLM714110 |
| BOLT | 1 | 1670304C1 |
| NUT, SHIFTER SHAFT POWER DIVIDER LOCK | 1 | 1696227C1 |
| SPRING, AXLE SHIFT PUSH ROD | 1 | 867718R1 |
| SHAFT, SHIFT FORK LOCK | 1 | KIT2825 |
| SHAFT, SHIFT FORK LOCK | 1 | 1670295C1 |
| CYLINDER, SHIFT DIFFERENTIAL SHIFT | 1 | 1696962C91 |
| CARRIER, DIFFERENTIAL W/BEARING CAPS | 1 | 2589354C1 |
| BOLT, CARRIER 12MM X 45MM L | 7 | MS2120452 |
| BOLT, CARRIER 12MM X 45MM L | 7 | 1696018C1 |
| GEAR SET, DIFFERENTIAL 3.91 | 1 | 2592703C91 |
| BEARING, CONE PINION | 1 | FPH715343 |
| CUP, BEARING PINION | 1 | FPH715311 |
| SPACER, PINION BEARING | 1 | 1670273C1 |
| GEAR, HELICAL DRIVE DIFFERENTIAL | 1 | 1670300C1 |
| CUP, BEARING | 1 | FP65500 |
| BEARING, CONE | 1 | FP65237 |
| WASHER, BEARING DIFFERENTIAL PINION GEAR | 1 | 1670271C1 |
| WASHER, FLAT | 7 | 2500348C1 |
| NUT, MOUNTING COMPANION FLANGE | 1 | 1670303C1 |
| COVER, BEARING CAGE DRIVE PIN GEAR | 1 | 1670299C1 |
| BOLT, PINION BEARING CAGE M10 X 45MM | 5 | 1696229C1 |
| ADJUSTER DIFFERENTIAL BEARING RIGHT | 1 | 1685506C1 |
| ADJUSTER DIFFERENTIAL BEARING LEFT /RIGHT 14051 | 1 | 1681827C1 |
| CUP, BEARING | 1 | FP592A |
| CUP, BEARING | 1 | FP52618 |
| BEARING, CONE | 1 | FP52400 |
| BEARING, CONE WHEEL | 1 | FP594A |
| BOLT, METRIC M16 X 110 MM | 12 | 1670306C1 |
| WASHER CARRIER TO HOUSING BOLT | 12 | 449671R1 |
| SEAL OIL INPUT SHAFT | 1 | 2502761C1 |
| SEAL OIL INPUT SHAFT | 1 | 573714C91 |
| BOLT, GEAR TO CASE M16 X 65 MM | 12 | 1696226C1 |
| WASHER, FLAT CAP BOLT CARRIER BEARING | 4 | 1653989C1 |
| BOLT, ADJUSTING LOCK M8 X 20 | 4 | 1691633C1 |
| PIN, DOWEL | 1 | 1670274C1 |
| WASHER, THRUST SIDE GEAR | 2 | 1653954C1 |
| GEAR, DIFFERENTIAL SIDE | 1 | 2234H1438 |
| GEAR, DIFFERENTIAL SIDE | 1 | 1653975C1 |
| SPIDER, DIFFERENTIAL | 1 | 1653981C91 |
| WASHER, THRUST PINION GEAR | 4 | 1653953C1 |
| CARRIER, DIFFERENTIAL INPUT SHAFT | 1 | 1685727C91 |
| NUT, HEXAGON LOCK METRIC | 12 | 1691622C1 |
| HARNESS, DIFFERENTIAL LOCK * SWITCH, WARNING LIGHT (ROCKWELL) | 1 | 2606013C91 |
| HARNESS, DIFFERENTIAL LOCK * SWITCH, WARNING LIGHT (ROCKWELL) | 1 | 2026065C91 |
| SPRING, SHIFT FORK | 1 | 1696233C1 |
| SHAFT, SHIFT FORK LOCK | 1 | 2603550C91 |
| SHAFT, SHIFT FORK LOCK | 1 | 1696232C1 |
| O-RING AIR CYLINDER | 1 | 1696234C1 |
| CYLINDER, SHIFT LOCK DIFFERENTIAL SHIFT LOCK | 1 | 1696231C91 |
| PIN, COTTER DIFFERENTIAL BEARING ADJUSTER LOCK | 1 | 683774R1 |
| BOLT, SHIFT CYLINDER | 1 | 1696236C1 |
| BEARING,CUP HG | 1 | 1228X648 |
| COLLAR, SHIFT CLUTCH 46 SPLINE | 1 | 1685507C1 |
| YOKE, SHIFT | 1 | 1696230C1 |
| O-RING | 1 | 1670307C1 |
| SHIELD, OIL FILTER | 1 | 2501793C1 |
| SPRING, INPUT SHAFT THRUST | 1 | 1670524C1 |
| VALVE, RELIEF | 1 | 1685730C1 |
| PUMP, DIFFERENTIAL OIL | 1 | 1691772C1 |
| WASHER, BOLT BEARING CAP | 3 | 483361C1 |
| BOLT, CARRIAGE | 6 | 1670495C1 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
