2589046C91
DIFFERENTIAL, REAR
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$5,799.95
$6,959.94
This is an oversize product. Additional shipping fees may apply.
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
DIFF ASSY RR DRIVE FIXED
Weight
243.51 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| YOKE, SLIP JOINT | 1 | 2601692C1 |
| WASHER, YOKE | 1 | 2589841C1 |
| SHIM, PINION CUP ,.005 | 3 | 2607627C1 |
| SHIM, PINION CUP ,.020 | 3 | 2607629C1 |
| SHIM, PINION CUP ,.007 | 3 | 2607628C1 |
| SHIM, DIFFERENTIAL BEARING CONE ,.005 | 6 | 2607630C1 |
| SHIM, DIFFERENTIAL BEARING CONE ,.020 | 6 | 2607632C1 |
| SHIM, DIFFERENTIAL BEARING CONE ,.007 | 6 | 2607631C1 |
| DIFFERENTIAL | 1 | 2607633C91 |
| BEARING, CUP | 2 | 2607639C1 |
| BEARING, CUP (REVERSE) | 1 | 2607634C1 |
| BEARING, CUP | 1 | 2607636C1 |
| SEAL OIL DROP BOX | 1 | 2589510C1 |
| BEARING, CONE (INPUT PINION) | 1 | 2607635C1 |
| BEARING, CONE | 2 | 2607640C1 |
| BEARING, CONE (INPUT PINION) | 1 | 2607638C1 |
| BEARING, BALL | 2 | 2607641C1 |
| RING, SNAP, BALL BEARING | 2 | 2607643C1 |
| RING, SNAP, INTERNAL | 2 | 2607644C1 |
| NUT, LOCK INPUT YOKE | 1 | 2589842C1 |
| BOLT ,H.H.C.S.-GRADE 8 | 12 | 2607645C1 |
| SCREW, HEXAGON FLANGE | 9 | 2607646C1 |
| PLUG, PIPE | 1 | 2607647C1 |
| BREATHER, AXLE | 1 | 2607648C1 |
| PLUG, MAGNETIC #8 O-RING | 1 | 2589512C1 |
| PLUG, FILLER | 1 | 2589876C1 |
| HOUSING, MAIN | 1 | 2607619C1 |
| COVER, MAIN | 1 | 2607620C1 |
| SHIM INPUT BEARING CONE .005 | 3 | 2607623C1 |
| SHIM INPUT BEARING CONE .007 | 3 | 2607624C1 |
| SHIM INPUT BEARING CONE .020 | 3 | 2607626C1 |
| SHAFT SIDE | 2 | 2607622C1 |
| SEAL SIDE SHAFT | 2 | 2607642C1 |
| GEAR, AND PINION ,SPIRAL BEVEL | 1 | 2607621C1 |
CROSS REFERENCES
- R CUSH 384A-1
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
