2588696C91
CARRIER ASSY
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$5,899.95
$7,079.94
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
DIFFERENTIAL, FORWARD /REAR 5.38
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| NUT, HEXAGON LOCK PINION | 1 | 1685173C1 |
| PUMP, DIFFERENTIAL OIL | 1 | 1691772C1 |
| BOLT | 6 | 1670495C1 |
| BOLT | 6 | 2508277C1 |
| WASHER, BOLT BEARING CAP | 6 | 483361C1 |
| SHAFT, INPUT POWER DIVIDER LOCK | 1 | 1691801C91 |
| WASHER, THRUST HELICAL /PINION GEAR | 1 | 2509646C1 |
| GEAR, HELICAL DRIVE DIFFERENTIAL | 1 | 1694576C1 |
| BOLT, INTERAXLE DIFFERENTIAL M10 X 45 MM | 8 | 1696237C1 |
| WASHER, NEOPREME LUBERFINER | 8 | 1658423C1 |
| WASHER, NEOPREME LUBERFINER | 8 | 1824866C1 |
| WASHER, FLAT PINION SHAFT WITH NUT 3" O.D. X 1.78" I.D. X .19" THICK | 1 | 264663C1 |
| SPIDER, DIFFERENTIAL | 1 | 1694573C1 |
| GEAR, SPIDER DIFFERENTIAL | 4 | 1694555C1 |
| WASHER, THRUST | 4 | 588968C1 |
| RING, SNAP | 1 | 1670296C1 |
| COLLAR, SHIFT CLUTCH | 1 | 2506149C1 |
| GEAR, SIDE DIFFERENTIAL | 1 | 1694570C1 |
| ADAPTER LUBE FILTER | 1 | 1670526C1 |
| CONE AND ROLLERS | 1 | JLM714149 |
| BEARING ROCKWELL QUICK SHIP | 1 | JLM714110 |
| VALVE, RELIEF | 1 | 1685730C1 |
| BOLT | 1 | 1670304C1 |
| NUT, SHIFTER SHAFT POWER DIVIDER LOCK | 1 | 1696227C1 |
| SPRING, AXLE SHIFT PUSH ROD | 1 | 867718R1 |
| SHAFT, SHIFT FORK LOCK | 1 | KIT2825 |
| SHAFT, SHIFT FORK LOCK | 1 | 1670295C1 |
| CYLINDER, SHIFT DIFFERENTIAL SHIFT | 1 | 1696962C91 |
| SCREEN, OIL FILTER | 1 | 1670482C1 |
| CARRIER, DIFFERENTIAL W/BEARING CAPS | 1 | 2589354C1 |
| BOLT 12 MM X 45 MM | 7 | 1697666C1 |
| GEAR SET SINGLE REDUCTION DIFFERENTIAL | 1 | 2589438C91 |
| BEARING, CONE | 1 | FPH715343 |
| BEARING, CONE | 1 | 860954R91 |
| CUP, BEARING PINION | 1 | H715311 |
| SHIM, BEARING SPACER PINION GEAR .005" | 1 | 242816R1 |
| SHIM PIN GEAR BEARING SPACER .003 | 1 | 242815R1 |
| SHIM, BEARING SPACER PINION GEAR .010" | 1 | 242817R1 |
| SPACER, PINION BEARING | 1 | 1670273C1 |
| SPACER, PINION BEARING INNER | 1 | 1694540C91 |
| SPACER, PINION BEARING INNER | 1 | 2502118C1 |
| GEAR, HELICAL DRIVEN DIFFERENTIAL | 1 | 2607893C1 |
| GEAR, HELICAL DRIVEN DIFFERENTIAL | 1 | 1694577C1 |
| SPACER, PINION BEARING .486" | 2 | 1670290C1 |
| SPACER, PINION BEARING .451" | 2 | 1670275C1 |
| SPACER, PINION BEARING .452" | 2 | 1670276C1 |
| SPACER, PINION BEARING .453" | 2 | 1670277C1 |
| SPACER, PINION BEARING .454" | 2 | 1670278C1 |
| SPACER, PINION BEARING .455" | 2 | 1670279C1 |
| SPACER, PINION BEARING .459" | 2 | 1670280C1 |
| SPACER, PINION BEARING .463" | 2 | 1670281C1 |
| SPACER, PINION BEARING .467" | 2 | 1670282C1 |
| SPACER, PINION BEARING | 2 | 1670283C1 |
| SPACER, PINION BEARING .474" | 2 | 1670284C1 |
| SPACER, PINION BEARING .478" | 2 | 1670285C1 |
| SPACER, PINION BEARING | 2 | 1670286C1 |
| SPACER, PINION BEARING .483" | 2 | 1670287C1 |
| SPACER, PINION BEARING | 2 | 1670289C1 |
| CUP, BEARING | 1 | FP65500 |
| CONE AND ROLLERS TA | 1 | 65237 |
| WASHER, BEARING DIFFERENTIAL PINION GEAR | 1 | 1670271C1 |
| WASHER, FLAT | 7 | 2500348C1 |
| COVER, BEARING CAGE DRIVE PIN GEAR | 1 | 1670299C1 |
| BOLT, PINION BEARING CAGE M10 X 45MM | 5 | 1696229C1 |
| ADJUSTER DIFFERENTIAL BEARING LEFT /RIGHT 14051 | 1 | 1681827C1 |
| ADJUSTER DIFFERENTIAL BEARING RIGHT | 1 | 1685506C1 |
| CUP, BEARING | 1 | TM592A |
| CUP TAPERED ROLLER | 1 | 52618 |
| CONE AND ROLLERS TA | 1 | 52400 |
| BEARING, CONE | 1 | TM594A |
| BOLT, METRIC M16 X 110 MM | 3 | 1670306C1 |
| WASHER CARRIER TO HOUSING BOLT | 24 | 449671R1 |
| CASE, DIFFERENTIAL 4.89-7.17 RATIO | 1 | 1681806C91 |
| SEAL, OIL INPUT SHAFT | 1 | 2502761C1 |
| BOLT, GEAR TO CASE M16 X 65 MM | 12 | 1696226C1 |
| WASHER, FLAT CAP BOLT CARRIER BEARING | 4 | 1653989C1 |
| BOLT, ADJUSTING LOCK M8 X 20 | 4 | 1691633C1 |
| BOLT DIFFERENTIAL BEARING LOCK ADJUSTING | 2 | 2586505C1 |
| WASHER, THRUST SIDE GEAR | 2 | 1653954C1 |
| GEAR, DIFFERENTIAL SIDE | 2 | 2234H1438 |
| GEAR, DIFFERENTIAL SIDE | 2 | 1653975C1 |
| SPIDER, DIFFERENTIAL | 1 | 1653981C91 |
| GEAR SET, SIDE AND PINION DIFFERENTIAL | 1 | 1653986C91 |
| WASHER, THRUST PINION GEAR | 4 | 1653953C1 |
| CARRIER, DIFFERENTIAL INPUT SHAFT | 1 | 1685727C91 |
| NUT, HEXAGON LOCK METRIC | 12 | 1691622C1 |
| BOLT, METRIC M6 X 12 | 1 | 1696022C1 |
| SHIM, BEARING CAGE INPUT SHAFT .005" | 1 | 1670292C1 |
| SHIM, BEARING CAGE INPUT SHAFT .003" | 2 | 1670291C1 |
| PLUG, CARRIER DIFFERENTIAL | 1 | 1696249C1 |
| O-RING | 2 | 1670307C1 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
